NDS DS-090N - Dura Slope Trench Drain Sections (Neutral Slope)
The NDS DS-090N Neutral Dura Slope Channel Drain is a high-performance drainage solution designed for efficient water management in residential and commercial applications. This innovative channel drain system offers superior durability and easy installation, making it the ideal choice for driveways, patios, pool decks, and other areas requiring effective surface water removal.
Key Features:
- Neutral slope design for versatile installation
- Durable, high-density polyethylene construction
- UV-resistant material for long-lasting performance
- Interlocking system for seamless connections
- Compatible with various grate options
Product Specifications:
- Length: 39.4 inches (1 meter)
- Width: 5.4 inches (137 mm)
- Height: 4.3 inches (109 mm)
- Material: High-density polyethylene (HDPE)
- Load class: Light duty to medium duty
- Flow rate: Up to 11.5 GPM (gallons per minute)
- Color: Black
Installation Instructions:
- Plan the drain layout and mark the area for excavation.
- Dig a trench approximately 8 inches wide and 6 inches deep, ensuring a slight slope for proper water flow.
- Pour a 2-inch layer of concrete as a base and allow it to set.
- Place the channel sections in the trench, starting from the outlet point. Ensure proper alignment and use the interlocking system to connect adjacent sections.
- Install end caps and outlet adapters as needed.
- Backfill around the channels with concrete, leaving space for the final surface material.
- Install the chosen grates by snapping them into place.
- Complete the surrounding surface installation, ensuring it's slightly higher than the grate for optimal drainage.
- Test the system by running water through it to confirm proper flow and drainage.
The NDS DS-090N Neutral Dura Slope Channel Drain offers a reliable and efficient drainage solution for various applications. Its durable construction and easy installation make it an excellent choice for both DIY enthusiasts and professional contractors.
