NDS 9381 - Slim Channel Fabricated 90 Degree Angle - White

NDS 9381 - Slim Channel Fabricated 90 Degree Angle - White

Colors: Gray (#9383), Sand (#9382) and White (#9381)

The NDS 9381 is a slim channel fabricated 90-degree angle fitting designed for efficient water drainage in landscaping and hardscaping applications. This sand-colored component seamlessly integrates with NDS Slim Channel systems, providing a sleek and discreet solution for managing surface water runoff. Ideal for residential and commercial projects, the NDS 9381 offers durability and performance in a compact design.

Installation Instructions:

1. Prepare the area by excavating a trench to the appropriate depth and width.
2. Ensure the trench base is level and compacted.
3. Place the 90-degree angle fitting at the desired corner location.
4. Connect adjacent Slim Channel sections to the fitting, ensuring a snug fit.
5. Use NDS connecting clips or adhesive to secure joints if needed.
6. Backfill around the installed components, compacting the soil as you go.
7. Install your chosen grate on top of the channel system.
8. Finish the surrounding area with your preferred landscaping material.

Product Specifications:

• Material: High-impact polypropylene
• Color: White
• Angle: 90 degrees
• Compatible with: NDS Slim Channel drainage system
• Load class: Suitable for pedestrian and light vehicle traffic
• UV resistant: Yes
• Chemical resistant: Yes
• Freeze-thaw cycle resistant: Yes

Features and Benefits:

• Low-profile design for discrete integration with surroundings
• Durable construction for long-lasting performance
• Easy to install and maintain
• Resists clogging and debris build-up
• Helps prevent water damage and erosion
• Ideal for patios, driveways, pool decks, and other hardscaped areas

Product and Technical Information

Sell Sheet - NDS Slim Channel Drain

Technical Sheet - NDS Slim Channel Drain Tees and Elbows

Technical Sheet - All Grates Flow Capacities
Installation Instructions - NDS Slim Channel Slab

Installation Instructions - NDS Slim Channel Pavers

Installation Instructions - NDS Slim Channel Landscape Traffic

CAD Drawing - NDS Slim Channel Slab

CAD Drawing - NDS Slim Channel Paver

CAD Drawing - NDS Slim Channel Landscape

CAD Drawing - NDS Slim Channel Outlets

FAQ - NDS Slim Channel

Video - NDS Slim Channel Parts & Features

Video - NDS Slim Channel Drain - Product Overview
